..DIMENSION(mm)
|
..NEEDLE LINE(LxWxH)
|
..5250x2550x1880
|
| |
..ASSEMBLY LINE
|
..3050x2050x1800 |
|
..PRINTING LINE
|
..1600x1200x1100 |
|
..GASKET ASSEMBLY LINE |
..1450x1000x1100 |
| ..WEIGHT (kg) |
..4500 |
..ELECTRICITY
|
..AC 220 x 2P, AC 380V
x3P |
| ..ELECTRIC CONSUMPTION |
..ABOUT 25Kw |
..AIR PRESSURE
|
..6Kg/cm2 |
| ..AIR CONSUMPTION |
..ABOUT 1500L/min. |
..PRODUCTION CAPACITY
|
..ABOUT 13,000~17,000PCS/HOUR |
..MAIN FRAME
|
..SS41, AL6061 |
| ..DISCHARGING VOLTAGE |
..25000V |
| ..INSPECTION |
..POINT TEST, BLOCKING
TEST |
| ..JIG |
..25PINS, 350PCS |
| ..WORKERS |
..5PERSONS (NEEDLE LINE
: 3 PERSONS, PRINTING : 1 PERSON, GASKET
..ASSEMBLY : 1 PERSON) |
| ..CONTROL SYSTEM |
..Electronic Control Circuit
with Programmable Logic Controller |
|
|
|
|
